China Stainless Steel Balls manufacturer

1010 C10 C15 Bicycle Carbon Steel Balls Automotive Bearing 15.875MM HRC55

Product Details:
Place of Origin: China
Brand Name: JN
Certification: SGS ISO
Model Number: 15.875MM 5/8 Inch
Payment & Shipping Terms:
Minimum Order Quantity: 500kg
Price: Negotiable
Packaging Details: Ploy bag+25kg carton box+1000kg wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union, MoneyGram,Paypal, L/C, D/A, D/P
Supply Ability: 25 Tons per Month

Detail Information

Product Name: Carbon Steel Balls Grade: G1000
Hardness: HRC55 Density: 7.82g/cm3
Young's Modulus: 200GPa Application: Automotive Bearing , Bicycle
High Light:

precision steel balls

,

soft steel balls

Product Description

1010 C10 C15 Bicycle Carbon Steel Balls Automotive Bearing Steel Ball 15.875MM



low carbon steel balls





                                           carbon steel ball
Feature: High hardness with a soft core giving resistance to shock load & excellent resistance to surface wear.
Hardness: Hardness is HRC 60 min. Reference the accompanying chart for minimum case depth.
Size Available: 1mm~ 50.8mm
Grade Available: G100~G1000
Material Conversion: ASTM/AISI DIN W-Nr. NF JIS
1015 CK15 1.2241 XC15 S 15C
Case Depth Ball Diameter Minimum Case Depth Ball Diameter Minimum Case Depth
2.0 -3.0mm 0.5mm 9.5 -11.0mm 1.4mm
3.1 -4.5mm 0.6mm 11.1 -12.5mm 1.7mm
4.6 -5.5mm 0.8mm 12.6 -14.0mm 1.8mm
5.6 -6.5mm 0.9mm 14.1 -19.0mm 1.9mm
6.6 -9.5mm 1.1mm 19.1 -38.0mm 2.0mm





 Chemical Composition



Type
%C
%Si
%Mn
%P
%S
1010
0.08-0.13
0.10-0.35
0.30-0.60
0.040 max
0.050 max
1015
0.12-0.18
0.10-0.35
0.30-0.60
0.040 max
0.050 max


Mechanical Properties



Property
Type
U.o.M.
Values
U.o.M.
Values
Hardness
Mechanical
[HRC]
55 - 65
-
-
Ultimate tensile strength
Mechanical
[MPa]
300 - 400
[psix10^3]
43 - 58
Service temperature
Thermal
[ºC]
-40 / 500
[ºF]
-40 / 932



International Standards



ITA
USA
GER
FRA
UK
RUS
CHN
JPN
C10
1010
1.1121
CC10
040A10
10
10
S10C
C15
1015
1.1141
XC12
080M15
15
15
S15C



Physical / mechanical / thermal / electric / magnetic properties

Property
Symbol
U.o.M.
Type
Notes
Values
Density
δ
[g/cm3]
Physical
Room temp.
7.82
Young's modulus
E
[GPa]
Mechanical
-
200
Specific heat
c
[J/kg-K]
Thermal
Room temp.
468
Coefficient of linear thermal expansion
α
[10^-6/ºC]
Thermal
(ΔT=0-100°C)
11.8
Thermal conductivity
λ
[W/(m·K)]
Thermal
Room temp.
57.9
Electric resistivity
ρ
[Ω*m*10^-9]
Electric
-
155
Relative magnetic permeability
µ
-
Magnetic
Ferromagnetic
> 500




1010 C10 C15 Bicycle Carbon Steel Balls Automotive Bearing 15.875MM HRC55 0
