China Stainless Steel Balls manufacturer

100cr6 Chrome Steel Balls For Polishing Milling 9MM 9.525MM 10MM 11.113MM G60

Product Details:
Place of Origin: China
Brand Name: JN
Certification: SGS ISO
Model Number: 9MM 9.525MM 10MM 11.113MM
Payment & Shipping Terms:
Minimum Order Quantity: 500kg
Price: Negotiable
Packaging Details: Ploy bag+25kg carton box+1000kg wooden box
Delivery Time: 7-15 days
Payment Terms: T/T, Western Union, MoneyGram,Paypal, L/C, D/A, D/P
Supply Ability: 50 Tons per Month

Detail Information

Produce Name: Chrome Steel Bearing Ball Grade: G60
Hardness: HRC58-65 HRC Standard: 100cr6
Tolerance: 0.002~0.02mm Refers To Grade Application: Polishing Milling Machine
High Light:

small round metal balls

,

tiny metal balls

Product Description

100cr6 Chrome Steel Ball For Polishing Milling 9MM 9.525MM 10MM 11.113MM G60





Characteristics



Low alloy hardened chromium steel balls, they show excellent hardness, wear resistance,

very good surface finishing and dimensional stability.

Applications

Precision bearings, automotive components (brakes, steering, line shaft), ball transfer units,

linear ball bearings, bike and motor-bike components, appliances, quick couplings,

machine tool, lock mechanisms, conveyor belts, skates, ball pens, pumps, castors,

measurement instruments, valves, recirculating balls.

Utilized in browning, polishing and milling machineries.


Chemical Composition


%C
%Si
%Mn
%P
%S
%Cr
%Mo
%Cu
%Al
%O
0.93-1.05
0.15-0.45
0.60-0.80
0.025 max
0.015 max
1.65-1.95
0.20-0.35
0.30 max
0.050 max
0.0015 max

Range

Diameters
U.o.M.
Diameters
U.o.M.
Precision grades (ISO 3290-1 / DIN 5401 / AFBMA)
0.250 - 300.000
[mm]
1/64 - 12
["]
G10-15-16-20-24-25-28-40-48-50-60-80-100-200-300-500-600-700-1000



Technical data

Property
Type
U.o.M.
Values
U.o.M.
Values
Hardness
Mechanical
[HRC]
60 - 66
-
-
Ultimate compressive strength
Mechanical
[MPa]
2500 - 2600
[psix10^3]
362 - 377
Service temperature
Thermal
[ºC]
-60 / 150
[ºF]
-76 / 302




100cr6 Chrome Steel Balls For Polishing Milling 9MM 9.525MM 10MM 11.113MM G60 0
