Product Details:
|
|
Place of Origin: | China |
---|---|
Brand Name: | JN |
Certification: | SGS ISO |
Model Number: | 3/32" 1/8" |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 500kg |
Price: | Negotiable |
Packaging Details: | Ploy bag+25kg carton box+1000kg wooden box |
Delivery Time: | 7-15 days |
Payment Terms: | T/T, Western Union, MoneyGram,Paypal, L/C, D/A, D/P |
Supply Ability: | 50 Tons per Month |
Detail Information |
|||
Produce Name: | Ball Bearing Balls | Grade: | G10 |
---|---|---|---|
Hardness: | HRC60-HRC65 | Application: | Bearing ,Grinding |
Tolerance: | +/-0.25um | Chrome Type: | 100CrMn6 , GCR15 |
High Light: | ball bearing steel ball,small round metal balls |
Product Description
G10 High Precision Chrome Steel Balls For Linear Rails Metal Bearing Balls Screw Bearing Balls
%C | %Si | %Mn | %P | %S | %Cr | %Ni | %Mo |
%Cu
|
---|---|---|---|---|---|---|---|---|
0.95-1.05 | 0.15-0.35 | 0.25-0.45 | 0.025 max | 0.025 max | 1.40-1.65 | 0.30 max | 0.08 max |
0.20 max
|
Property | Type | U.o.M. | Values | U.o.M. |
Values
|
---|---|---|---|---|---|
Hardness | Mechanical | [HRC] | 60 - 66 | - |
-
|
Ultimate compressive strength | Mechanical | [MPa] | 2500 - 2600 | [psix10^3] |
362 - 377
|
Service temperature | Thermal | [ºC] | -60 / 150 | [ºF] |
-76 / 302
|
Shandong Jinnai is a professional manufacture and supplier of steel balls and ball related products in China .
We offer solid ball size from 0.1mm-500mm stainless steel ball (201, 304, 316, 420,420C,430,440),
chrome steel ball,carbon steel ball,copper/brass balls, plastic ball,glass ball,tungsten carbide ball,
flying saucer ball,ceramic ball,aluminum balls for 15 years experiences.
Our products are widely used for bearings,valves,sprayers, sliders, perfume bottles, nail polish,
motor, switch, electric iron, washing machines, refrigerators, air conditioners, medicinal materials,
auto parts,instrument,bottles,pulley, precision machinery, etc.
